Brakes
Brake Type : Pwr
Brake ABS System : 4-Wheel
Disc – Front (Yes or ) : Yes
Disc – Rear (Yes or ) : Yes
Front Brake Rotor Diam x Thickness (in) : 11.7 x – TBD -
Rear Brake Rotor Diam x Thickness (in) : 12.0 x – TBD -
Drum – Rear (Yes or )
Rear Drum Diam x Width (in)
Cargo Area Dimensions
Cargo Area Length @ Floor to Seat 1 (in) : – TBD -
Cargo Area Length @ Floor to Seat 2 (in) : – TBD -
Cargo Area Length @ Floor to Seat 3 (in)
Cargo Area Width @ Beltline (in) : – TBD -
Cargo Box Width @ Wheelhousings (in) : – TBD -
Cargo Box (Area) Height (in) : – TBD -
Cargo Volume to Seat 1 (ft³) : 72.9
Cargo Volume to Seat 2 (ft³) : 35.7
Cargo Volume to Seat 3 (ft³)
Cooling System
Total Cooling System Capacity (qts) : 7.0
Electrical
Cold Cranking Amps @ 0° F (Primary) : – TBD -
Maximum Alternator Capacity (amps) : – TBD -
Engine
Engine Order Code
Engine Type : Gas I4
Displacement : 2.4L/144
Fuel System : MPFI
SAE Net Horsepower @ RPM : 180 @ 6800
SAE Net Torque @ RPM : 161 @ 4400
Exterior Dimensions
Wheelbase (in) : 103.1
Length, Overall (in) : 179.3
Width, Max w/o mirrors (in) : 71.6
Height, Overall (in) : 66.1
Track Width, Front (in) : 61.6
Track Width, Rear (in) : 61.6
Min Ground Clearance (in) : 6.7
Rear Door Opening Height (in) : – TBD -
Rear Door Opening Width (in) : – TBD -
Liftover Height (in) : – TBD -
Fuel Tank
Fuel Tank Capacity, Approx (gal) : 15.3
Interior Dimensions
Passenger Capacity : 5
Passenger Volume (ft³) : 100.9
Front Head Room (in) : 38.9
Front Leg Room (in) : 41.3
Front Shoulder Room (in) : 56.9
Front Hip Room (in) : 55.9
Second Head Room (in) : 38.5
Second Leg Room (in) : 38.5
Second Shoulder Room (in) : 56.0
Second Hip Room (in) : 54.6
Mileage
Fuel Economy Est-Combined (MPG) : – TBD -
EPA Fuel Economy Est – City (MPG) : – TBD -
EPA Fuel Economy Est – Hwy (MPG) : – TBD -
Steering
Steering Type : Pwr Rack & Pinion
Steering Ratio (:1), Overall : 15.74
Lock to Lock Turns (Steering) : 2.96
Turning Diameter – Curb to Curb (ft) : 37.8
Turning Diameter – Wall to Wall (ft) : – TBD -
Summary
Vehicle Name : CR-V
Body Style : 5 Door
Suspension
Suspension Type – Front : Independent
Suspension Type – Rear : Independent
Suspension Type – Front (Cont.) : MacPherson Strut
Suspension Type – Rear (Cont.) : Multi-link
Shock Absorber Diameter – Front (mm) : – TBD -
Shock Absorber Diameter – Rear (mm) : – TBD -
Stabilizer Bar Diameter – Front (in) : 0.79
Stabilizer Bar Diameter – Rear (in) : 0.75
Tires
Front Tire Order Code
Rear Tire Order Code
Spare Tire Order Code
Front Tire Size : P225/65TR17
Rear Tire Size : P225/65TR17
Spare Tire Size : – TBD -
Trailering
Dead Weight Hitch – Max Trailer Wt. (lbs) : 1500
Dead Weight Hitch – Max Tongue Wt. (lbs) : 150
Wt Distributing Hitch – Max Trailer Wt. (lbs)
Wt Distributing Hitch – Max Tongue Wt. (lbs)
Transmission
Drivetrain : Front Wheel Drive
Trans Order Code
Trans Type : 5
Trans Description Cont. : Automatic
Trans Description Cont. Again
First Gear Ratio (:1) : 2.79
Second Gear Ratio (:1) : 1.61
Third Gear Ratio (:1) : 1.08
Fourth Gear Ratio (:1) : 0.77
Fifth Gear Ratio (:1) : 0.57
Sixth Gear Ratio (:1)
Reverse Ratio (:1) : 2.00
Clutch Size (in)
Final Drive Axle Ratio (:1) : 4.50
Transfer Case Gear Ratio (:1), High : – TBD -
Transfer Case Gear Ratio (:1), Low : – TBD -
Vehicle
EPA Classification : 2WD Sport Utility
EPA Greenhouse Gas Score : – TBD -
Weight Information
Base Curb Weight (lbs) : 3413
Wheels
Front Wheel Size (in) : 17 x – TBD -
Rear Wheel Size (in) : 17 x – TBD -
Spare Wheel Size (in) : Compact
Front Wheel Material : Aluminum
Rear Wheel Material : Aluminum
